Function feature and the principle of action.
This machine is suitable for crushing thermal sensitive material and
granulating for damp material. It is less the heat and the powder dust.
The sieve of stator is made of stainless steel plate. It is not easy to damage.
The gap between crushing blade and sieve can be adjusted.
Can treat material that is adhesive or in gum or heat or damp state.
| Number | Item | Unit | Model/specification |
| 1 | Capacity | Kg/h | 100-500 |
| 2 | Mesh size | mm | 1.2mm,1.5mm,3mm |
| 3 | Power | kw | 4 |
| 4 | Rotating speed | rpm | 200~1000 |
This grinding granulator machine could be combined using with tablet press machine for recycling of unqualified tablets.
