Chinese Herb Medicine Mill Machine (20B)

  • Shanghai, China
  • 1000PCS/Y
  • L/C, T/T, Western Union
  • B
  • Non-Customized
  • New
  • 1 Year
  • for Chemical or Pharmaceutical Industry
  • 12
  • 120
  • 550kg
  • 40-800kg/H
  • 380V, 50Hz
  • 2
  • SY
  • Polywood Packaging.
  • CE
  • Jiangsu Province
  • 8479820090
  • Preparation Machinery
  • Granules
  • High Precision
  • CE, GMP, ISO
  • 380V
  • Computerized
This Universal dust absorption pulverizer set is suitable for pharmaceutical, chemical and foodstuff industries, etc. Fully made of stainless steel and GMP standard. It is a new generation of pulverizer with durable working life and reliable quality.
1. All kinds of food contain sesame seed, walnut, rice, black rice, beans, mung beans, peanuts, lotus seed,
corn, sorghum, barley, buckwheat, oats, etc;
2. All kinds of dried herbs containing almonds, poria cocos, red jujube, Gordon euryale seed, medlar, yi,
hawthorn, HuaiShan, radix polygoni multiflori, red bean, donkey-hide gelatin, frankincense, dodder, angelica, dangshen, astragalus membranaceus,
3. All kinds of chemical raw materials including coal, gypsum, salt, acid.
4. All kinds of spices, pepper, pepper, Chinese prickly ash, star anise, cinnamon and etc.
Main features
The machine adopts the high-speed spinning blade of wind wheel and stationary knife. It has advantages of low noise, light vibration and no dust flying in the course of production. This is according with the requirement of GMP.

Working principle
The machine has a relative movement between the moving gear tray and the fixed tray to pulverize the material. The materials are pulverized by gear impacting mutual impacting anc friction. The ground material automatically enters the collecting bag under the action of the eccentric force, and it is discharged from the dust absorption box through filtering bags.

Technicial Parameters:
Model 20B 30B 40B 60B
Capacity(kg/h) 20-150 30-300 40-800 60-1200
Speed of principal axis(r/min) 4500 3800 3400 2600
Size of input granules(mm) ≤6 ≤10 ≤12 ≤15
Fineness of products(mesh) 12-120 12-120 12-120 12-120
Power(kw) 4 5.5 11 22
Weight(kg) 200 320 550 960
Overall size(L×W×H)(mm) 650×500×1250 750×600×1450 900×700×1800 1000×950×1800

Chinese Herb Medicine Mill Machine (20B)
Chinese Herb Medicine Mill Machine (20B)

Chinese Herb Medicine Mill Machine (20B)
Welcome to check with us about the technical parameters of the pulverizer. We provide rough pulverizer for herbs, food and etc, customized high efficient pulverizers for herbs and seasonings, and hammer mill etc with various working capacity for your different demands of our clients. Welcome to send us the specific requirements, we will send you the best design and offer soon.
