NJP-2-6000C Automatic Capsule Filling Machine

NJP-6000C is a mass production equipment.
The high precision fully automatic capsule Filling Machine is used to fill powderor granules in the form of slug in hard gelatin capsules.

Quantity:


NJP-6000C is a mass production equipment.

The high precision fully automatic capsule Filling Machine is used to fill powderor granules in the form of slug in hard gelatin capsules.

It is working with high speed, a high performance that incorporates latest international

design and is built with precision using most appropriate material and up to date manufacturing systems. Different models are available for various output requirements. It is designed to cater various formulations with option to fill powder, granules and pellets.

Its automatic filling demands very high accuracy besides high productivity, ease of operation

and minimum maintenance. This machine has been specifically designed to meet all these

Requirements.


Features

1. Tamping Mechanism enables capsules to be filled with a weight variation of 2%.

2. Faulty capsule and filled capsule ejection stations with individual air controls.

3.Quick changeover for a variety of capsule sizes with minimal follow-up adjustments and maintenance requirements.

4. closed system protect your product from contaminants, and allow a dust-free production  environment for better health and easier cleanin
5.Adjustable gap between dosing disk and tamping plate ensures minimum spillage of powder.
6. PLC & Touch screen control system.
7.All contact parts are made of corrosion resistant stainless steel 316.
8.Automatic vacuum removal of the air in the dosing tube to give more accurate weight of the filled capsules.
9. Add the extra function of capsule control switch. Control the capsule outside of the machine that makes more safe
10.  click-moving control system, easy operation and clearness.
11. Safety System
Machine stops automatically in the event of following problems through safety interlock system.
· No capsules
· No powder/no granules
· Door open




Model

NJP-6000C

Max.Capacity

360000 capsules/hr

No. of segment bores

43

Machine weight

3000kg

Machine Dimension

1500*1250*2200mm

Power supply

380V,  50/60 HZ   (For customer to designate)

Total power

11kw

Vacuum

-0.02~0.06Mpa

Compressed air

1pressure   0.3-0.4Mpa   air consumption 0.2m³ /min

Noise

< 80DB (A)

Filling percentage

Empty capsule 99.9%
Full capsule over 99.5%

Capsule size

00#-5#

Filling

± 3%-± 4%

suitable for filling

powder, granule, pellet, mini tablet
