Wcsj Vertical High Efficiency Universal Coarse Crusher

Quantity:



Inquire

Port:
Shanghai, China
Production Capacity:
80
Payment Terms:
L/C, T/T, Western Union
Model NO.:
WCSJ
Cutter Material:
High-Speed Steel
Finished Surface:
Outer Surface Process
Compressive Strength (For Crushing):
>300MPA
Tongs′ Features:
Universal Tongs
Weight:
300kg
Cbm:
5.5cbm
Transport Package:
Wooden Case
Specification:
100-500KG
Origin:
Jiangsu
HS Code:
8479820090
Type:
Jaw Crusher
Object:
Plastic
Drive:
Electric
Crushing Degree:
Coarse Crusher
Crushing Style:
Grinding and Impact
Principle:
Fixed Culling

Product Description

It is applied for the industry of pharmaceutical, food and chemical for the step of before materials arefine grinded.

1) Vertical crushing structure
2) The material is fed into the crushing chamber through a hopper
3) Crushed by simultaneous cutting of both fixed and movable knives and rotating impact of rotating knife
4) Flowed to the exit automatically under the effect of rotating centrifugal force.

Technical parameters of WCSJ-20 and WCSJ-320:

Model	Production Capacity	Spindle speed	Feeding Size	Output Size	Motor Power	Overall dimension	Weight
WCSJ-20	100-500kg/h	960r/min	< =100mm	0.5-20mm	5.5kw	3000× 850× 2300mm	300kg
WCSJ-320	300-1200kg/h	1070r/min	< =100mm	0.5-20mm	11kw	3500× 850× 2380mm	600kg

Grinder Pulverizing Machine Crusher
