Juice Smoothie Blender & Colloid Mill (JMS model)

Quantity:
  • Shanghai, China
  • 7200PCS/Y
  • L/C, T/T, Western Union
  • JMS
  • Non-Customized
  • for Food, Chemical, Daily Chemical Industry
  • for Peanut Sauces
  • Could Be Vertical, Horizontal
  • hy
  • Wooden Case for Export
  • CE
  • Zhejiang Province
  • 8479820090
  • Colloid Mill
  • All, Beans, Wheat
  • 220V
  • Horizontal
  • Aloe Vera, Pineapple, Sesame, Tea, Ice Cream etc.
  • New

Classification
1. According to structure
Vertical Colloid Mill and Split Colloid Mill. And each type has various models for choose.

2. According to appearance
Sanitary colloid mill and common colloid mill.

Working principle:
The liquid or semi liquid under the centrifugal work to cut, touch, move through the high speed wheel,
and it has efficiency to crash, dairy, homogenization, separate, mix, then you can have
the currency material.

The high speed move between the wheels is the main insurance to
get the tiny material. Improve the wheel's speed could reach the high efficiency,
so the Colloid Mold wheel's speed of our factory at 1000 m/minute. Because high speed move
could produce lots of hot, and each equipment produce currency should very high, also need cooling,
so the Colloid Mold for our factory has one or two cooling step.


Application range:
It is widely used in food industry, medicine industry, chemical industry, daily industry etc such as soy,
fruit sauce, peanut sauce, milk sauce, dyestuff, flower powder, etc.




Juice Smoothie Blender & Colloid Mill (JMS model)


Juice Smoothie Blender & Colloid Mill (JMS model)
Juice Smoothie Blender & Colloid Mill (JMS model)
1, the food industry: aloe, pineapple, sesame, tea, ice cream, moon cake stuffing, cream, jam, fruit juice, soybean, bean paste, red bean milk, peanut milk, protein, soy milk, dairy products, malted milk, essence and various beverages.

2, chemical industry: paint, pigment, dyestuff, paint, lubricating oil, grease, diesel oil, petroleum catalyst, emulsion, adhesives, detergents, plastics, asphalt, glass fiber reinforced plastic, leather, emulsification, etc.

3, daily chemical industry: toothpaste, detergent, shampoo, shoe polish, cosmetics, liquor, soap, face cream, etc.

4, the pharmaceutical industry: various syrup, nutrient solution, proprietary Chinese medicine, paste reagent, biological products, cod liver oil, pollen, royal jelly, vaccine, all kinds of ointment, a variety of oral solution, injection, static drops, etc.

5, building industry: all kinds of coating.Including external coatings, anti-corrosion waterproof coating, cold porcelain paint, colorful coating, ceramic glaze, etc.

6, other industries: plastic industry, textile industry, papermaking industry, coal flotation
agent, nanometer materials and other industries the production of high grade environmental protection is need.

Model JML-50 JML-80 JML-100 JML-120 JMF-80 JMF-100 JMF-120 JMF-140 JMF-180
Emulsifying fitness/um 5~40 3~40 2~40 2~40 3~40 2~40 2~40 2~40 2~40
Regulation range /mm 1-0.01 1-0.01 1-0.01 1-0.01 1-0.01 1-0.01 1-0.01 1-0.01 1-0.01
Capacity t/h Change according to the material
0.01-0.2 0.3-1 0.5-2 0.7-3 0.3-1 0.5-2 0.7-3 1-4 2-5
Motor
Power/kw 1.1 3 5.5 7.5 4 5.5 7.5 11 15
Voltage/v 380 380 380 380 380 380 380 380 380
Speed/rpm 2880 2880 2880 2880 2880 2880 2880 2880 2880
Burrs diameter /mm φ50 φ80 φ100 φ120 φ80 φ100 φ120 φ140 φ180
Outlet diameter φ15 φ25 φ32 φ40 φ25 φ32 φ40 φ40 φ65
Internet diameter φ32 φ50 φ50 φ65 φ50 φ50 φ65 φ80 φ120
Diameter of cooling pipe φ1/8″ φ1/4″ φ1/4″ φ1/4″ φ1/4″ φ1/4″ φ1/4″ φ1/4″ φ1/4″
Size Lenght/mm 420 520 560 560 640 750 750 820 980
Width/mm 280 400 420 420 550 620 620 700 800
Height/mm 760 900 950 950 1030 1080 1080 1250 1550
Weight/kg 45 84 113 135 210 275 295 325 450
