High Quality Pulverizing Machine/Mill/Grinder/Milling Machine (30B)

Quantity:



Inquire

Port:
Shanghai, China
Production Capacity:
40/Month
Payment Terms:
L/C, T/T, Western Union
Model NO.:
WF
Cutter Material:
High-Speed Steel
Finished Surface:
Outer Surface Process
Compressive Strength (For Crushing):
>300MPA
Tongs′ Features:
Adjustable Tongs
Weight:
550kg
Input Size:
<10mm
Fineness:
12-120mesh
Trademark:
SYQ
Transport Package:
Wood
Specification:
5.5kw
Origin:
Jiangsu
HS Code:
84791000
Type:
Impact Crusher
Object:
Chemicals, Food, Pharmaceutical Materials
Drive:
Electric
Crushing Degree:
Fine Grinding Machine
Crushing Style:
Grinding and Impact
Principle:
Fixed Culling

Product Description

(1) The machine is mainly applied for grinding for various grains, dry spices and herbs,
herbal medicines containing roots and branches, chemical materials, and some other hard and brittle materials.

The materials it could grind:
grains,roasted coffee bean,spices,herbs,salt,sugar,pepper,walnut shells,seed,etc.
After grinding, fine powder can be made.the trades of pharmaceutics, chemical and foodstuff, etc.

(2) The machine is with relative movement between the active fluted disc and the fixed fluted disc to impact, grind and crush the target materials.

(3) The crushed material can enter the collection box by the centrifugal force.

(4) The dust from grinding is filtered and recycled via the cloth bag or filter of the dust absorption box.

(5) The whole machine, designed according to GMP standard, is made of stainless steel, easy washing

(6) The machine avoids dust flying during process of working, mostly improve the utilization of raw material and decrease the production cost.

Technicial Parameters:

Model	20B	30B	40B	60B
Capacity(kg/h)	20-150	30-300	40-800	60-1200
Speed of principal axis(r/min)	4500	3800	3400	2600
Size of input granules(mm)	< 6	< 10	< 12	< 15
Fineness of products	12-120	12-120	12-120	12-120
Grinding power(kw)	4	5.5	7.5	15
Dust absorption power(kw)	1.5	1.5	1.5	1.5
Weight(kg)	350	420	580	750
Overall size(L× W× H)(mm)	1100× 500 × 1650	1200× 600 × 1650	1350× 750 × 1700	1650× 950 × 2100

Grinding Machine Pulverizer Pulverizing Machine
